China factory hot selling p10 led module full color display screen for fixed installation
P10 LED Module 320mmx160mm datasheet :
| Pixel pitch | 10mm |
| Pixel Density | 10,000 dots/m² |
| Pixel configuration | RGB |
| LED type | SMD3535 |
| Module size | 320*160mm |
| Module weight | 0.7Kg |
| Module resolution | 32*16dots |
| Module quantity | 20 pcs/m² |
| Min. Viewing Distance | ≥10m |
| Brightness | ≥6200 cd/m² |
| Viewing Angle | H≤110° V≤50° |
| Driving Mode | 1/4 scan constant current |
| Interface | HUB75 |
| Input voltage | 4.8-5.5VDC |
| Max. Power Consumption | 700 w/m² |
| Avg. Power Consumption | 650 w/m² |
| Max. Current | 2.6-2.9A |
| Frame rate | 60 frames/s |
| Refresh Rate | ≥200Hz |
| Defective Dots Rate | <0.0001 (LED display line standard: ≤ 0.0003) |
| Decay Rate | ≤5%/year |
| Brightness Conformity | >95% |
| MTBF | ≥10000 hours |
| Lifespan | ≥100000 hours |
| Protective function | Over-heat/Over-load /Power-down /Power-leakage/Lightning
-protection etc. |
| Operating Temperature | -20℃~+50℃ |
| Operating Humidity | 10-85% no condensation |
| Storage Temperature | -30℃~+60℃ |
| Storage Humidity | 10-95% no condensation |
